8 – ENABLE function (Interbus-s)
Pressure PA
ENABLE 24V
Si
g
nal
24V_Power
P/2
servovalve activ
servovalve inactive
0-10V/4-20mA
0V
Inpunt Interbus Fase
ENABLE
(
Bit 2
)
Servovalve
Control
Signal behaviour
:
ENABLE 24V
: This function allows the valve control when voltage power supply interrupts
(Fail save); the output current pressure is not modified.
Servovalve control Interbus input
: This function allows the servovalve piloting to be
done through the Interbus control input (Active High = ENABLE goes to 0V ->): pressure
stays unchanged.
