Weld334m - User’s manual

67

APPENDIX

Table of Contents

Default Chapter3
- Table of Contents3
- White Page6
Safety7
- Hazards Associated with the Use of Resistance Welding Machines8
- Observations on Connections10
Characteristics and General Description of the Weld334M15
Power Supply and 24V for I/O21
F351-Bus Interconnection Card29
F384-Cpu Microprocessor Card31
F353-Adc Analogue Card33
- P3 E P4 . Description of the Analogue Inputs33
- P2 . Description of the Signals for the Solenoid Valve and the Tfe34
F364-Sev and F385-Sev: Proportional Servovalve Modules37
- Servovalve Adjust37
  - Voltage Outlet Characteristics38
  - Current Outlet Characteristics38
- Connection of the F364 / F385-Sev Module on the F353-Adc Card38
  - Jumper Function on Connector J439
  - Jumper Function on Connector J539
F359-Mcp Memory Card and Printer41
F360-Iob Card - Base I/O43
F356-Ioe I/O Expansion Card47
- P23 . Description of Output Signals47
- P24 . Description of Input Signals50
  - List of Program Selection Codes53
F376-Opc Field-Bus Interbus-S Card (Profile F-Ibs/03)55
F386 Ethernet 100Base-T and Canbus Communication Module59
F383-Com Rs422 Serial Communication Card63
- P15 - Connection Port63
Interbus-S Profil F-Ibs/0365
- General Description65
  - Control Words65
  - Status Words69
- Robot Directives Update72
Appendix73
