Weld334m - User’s manual
71
Replacing the welding control device
Times indicated refer to a manual welding station
1 Saving the configuration and programs of the control device to
be replaced on a Ram-Card
1
Minute
2 Dismantling the control device to be replaced from the welding
machine support
3
Minutes
3 Mounting the new control device 3
Minutes
4 Switching On the new control device and verification that no
diagnostics alarms are On
1
Minute
5 Inserting the Ram-Card and loading the programs and the
configuration of the new control device
1
Minute
Time for replacing the device totals to 9 minutes (approx.).
Modifying a welding program:
The operation is to be carried out by qualified personnel with optimum knowledge of the
control device programming.
Time taken up to modify a program depends on the entity of the change:
If only one parameter is to be modified, for instance the welding current value, the
operation will take about 45” via the HCM4300 programming unit.
By contrast, if more parameters are to be modified, time can be calculated averagely, by
adding approx. 30” for opening the menu concerned to approximately 10” for each
modified parameter.
Time for modifying 1 parameter : 45"
∼
Time for modifying “n” parameters : 30" + 10 x n
