GF Welding Weld334m - P24. Description of Input Signals

Weld334m - User’s manual
F356-IOE I/O Expansion Card
44
10.2 P24 . Description of input signals
18-way, 3.5mm pitch linear connector for disconnectable terminals
Pin Signal Description
1 STARTA Start channel A
2 STARTB Start channel B
3 CEVASA Additional opening A control
4 CEVASB Additional opening B control
5 SALDASI Weld Yes
6 SOLOPR Pressure only
7 RESASA Stepper A alarm reset
8 RESASB Stepper B alarm reset
9 RAVOK Dressing done
10 CHGEOK Electrodes change done
11 CODE0 Bit 0 program code
12 CODE1 Bit 1 program code
13 CODE2 Bit 2 program code
14 CODE3 Bit 3 program code
15 CODE4 Bit 4 program code
16 CODE5 Bit 5 program code
17 CODEP Program code parity code
18 RESAH Alarm 2 reset
P24 . Functional description of input signals
Pin Signal Function
1 STARTA
Channel A Start.
Active at +24V.
The control device activates the EVSA output (Gun A call)
and executes the welding program demanded.
If Start is interrupted before the pressure cycles have
elapsed, the EVSA output is deactivated and electrodes open.
When pressure cycles are got over, the Start signal stays in
the self-holding mode up to the end of the frequency cycles.
2 STARTB
Same as STARTA but for channel B.
3 CEVASA
Control to solenoid valve for additional opening A.
Active at +24V.
Start of electrodes pre-approach; it is enabled and disabled
with 0 to 24V ramp up, (pulse type).
Signal reading time < 100mS.
If not used, this input is to be connected directly to +24V.
4 CEVASB
Same as CEVASA but for channel B.
