8. F359-MCP Memory Card and Printer
The F359-MCP card supports a PCMCIA type memory card (Ram Card) and
the parallel port for connection to a printer.
MEMORY CARD
Standard connector for the PCMCIA card.
The memory card allows saving the configuration as well as all the welding
programs of a control device or memorising the operating software.
Thus, you are given the facility to perform two maintenance operations
quickly and in an easy way.
The first operation concerns the immediate replacement of a welding
control device.
Thanks to the Ram Card all data is quickly transferred from one device to
another with no need to configure and hand copy all the programs to the
new control device.
The second operation is the operating software update through by a
simple loading operation. In addition, the operating system can be
transferred from one control device to another.
For the correct use of the Ram Card, please consult the Programming
Manual, chapter MEMORY CARD.
P5 - PRINTER
25-way Sub-d socket connector
The parallel port allows the connection to a (parallel) printer for printing
data concerning the programs, steppers, reports, etc…
For this function, please consult the W334m Programming Manual.
To connect the printer, a standard cable for printers is sufficient
(Centronics type – 25-way parallel cable)
WARNING!
This port is not compatible with serial printers
No setting jumpers are on the card.
F359-MDP
