Weld334m - User’s manual
InterBus-S Profil F-IBS/03
64
mode or constant current).
7 STATUS Bit = 1.
Execute “welding cycle with current”
enabled.
The welding cycle will be executed with current,
that is to say under command of the power group.
8
Danger Alarm
(Circuit br. trip.)
Bit = 1
. Signals that the control has detected the
condition of “current without start
"
.
9 STSERV Bit = 1
. Signals that the proportional valve has
reached the required setup value.
10 MAXPWR Bit = 1
. Signals that the control is operating with
the minimum admissible striking angle.
11 UNDERCURRENT Bit = 1
. Signals that the welding current
measured is below the minimum tolerance
admissible.
12 Hardware Alarm
(ALARM 2)
Bit = 1
. Signals the presence of an alarm with
error code
>
50 (planned alarm).
13/15
-Not used
Status Word 2
Status Word 2 defines the commands relating to the management of supplementary
stepper functions and of accessory functions.
Bit Description
0 Reset stepper gun 1
1 Reset stepper gun 2
2 Reset stepper gun 3
3 Reset stepper gun 4
4 Reset stepper gun 5
5 Reset stepper gun 6
6 Reset stepper gun 7
7 Reset stepper gun 8
8Not used
9Not used
10 Not used
11 Not used
12 Not used
13 Not used
14 Not used
15 Communication fault
Status Word 2 – Functional description
Bit Signal Function
0/7 Reset stepper
gun 1
÷
÷÷
÷
8
Bit = 1.
Stepper gun no. reset.
Resetting of stepper counter no. is confirmed. (see
description of spec.s at par. 14.2).
8/14 -
Not used.
15 Communication
Fault
Error during storage on network support of data
relating to the protocol function for test pieces
