Page C-8 MDE-4699L Applause™ Media System Installation, Service, and Parts Manual · June 2017
Configuring Site Server IP Addresses for Applause
Media System (when IP Addresses Are Changed)
Configuring Network for Gilbarco Dispenser IP Addresses
Set CRIND Side A IP
From the Set IP Addresses menu, press 1 > Enter. The CRIND Side A IP screen appears.
Figure C-9: CRIND Side A IP
CRIND Side A IP
000 . 000 . 000 . 000
Enter number blocks using three digits each with
leading zeros if necessary.
IP block range: 000 – 255
Example: 010 . 005 . 126 . 003
Clear = Erase Entry
Enter = Save Value and Exit
Cancel = Discard Changes and Exit
To set side A IP address, number block must be in the 000-255 range and must be completed
with leading zeros.
• Press Cle
ar to erase all entered digits and start again.
• Press Enter
to validate if it is a correct IP address and to store the result, if IP address is
not valid the input is cleared.
• Press Cancel to
discard the input and return to Set IP Addresses menu.
Note: Set CRIND Side B IP option is not visible on single side units.
Set SMART Merchandising Server IP
From the Set IP Addresses menu, press 4 > Enter. The SMART Merchandising IP screen
appears.
Figure C-10: SMART Merchandising IP
SMART Merchandising IP
000 . 000 . 000 . 000
Enter number blocks using three digits
each with leading zeros if necessary.
IP block range: 000 – 255
Example: 010 . 005 . 126 . 003
Clear = Erase Entry
Enter = Save Value and Exit
Cancel = Discard Changes and Exit
To set SMART Merchandising Server IP address, number block must be in the 000-255 range
and must be completed with leading zeros.
• Press Cle
ar to erase all entered digits and start again.
• Press Enter to
validate if it is a correct IP address and to store the result, if IP address is
not valid the input is cleared.
• Press Cancel to
discard the input and return to Set IP Addresses menu.
