GILBARCO VEEDER-ROOT Orpak OrPAY1000 User Manual

9 8 7 6 5 4 3 2 1
E G - + G - +
Channel 2/4 Channel 1/3
Table 2-8 - RS-485 Connector Pinout
2.4. Specifications
The following details OrPAY1000's specifications and external interfaces.
2.4.1. General Specifications
The following table details the general specifications for OrPAY1000 (see Table 2-9):
Parameter Value
PHYSICAL
Dimensions
(HxWxD)
164 mm x 179 mm x 35.5 mm (6.456" x 7.047" x 1.397")
Weight 600 grams
Rear Panel
(HxW)
149 mm x 135 mm (5.866" x 5.314")
Rear Panel -
cable door
(HxW)
157.2 mm x 43.6 mm (6.188" x 1.716")
ELECTRICAL
Input Voltage 24VDC ±10% (terminal can be operated in the range 12-24VDC depending on local
rules)
Power
Consumption
4A
ENVIRONMENTAL
Operational
Temperature
-40°C ≤ Ta ≤ +65°C
-30°C ≤ Ta ≤ +60°C (with barcode reader)
Storage
Temperature
-40°C ≤ Ta ≤ +85°C
Humidity 95% non-condensing
Vibration IEC 60945 §8.7
Ingress
Protection
IP65
Table 2-9 - General Specifications
OrPAY1000 Installation and Setup Manual 7
