Figure 4-7 - Ground Tab

4.3.2. Ground and Power Cable

OrPAY1000 is provided with a ground tab mounted on the bottom frame (see figure below).

The tab must be connected to the pump (or cabinet) frame to provide protection from both power faults and

static discharges. The cable supplied with the product includes:

The ground wire

Two DCpower wires, (+) and (-)

Two RS-485 wires, (+) and (-)

OrPAY1000 Installation and Setup Manual 32
