2. Click Apply. The following dialog appears (see Figure 5-33):
Figure 5-33 - Confirm Save Dialog
3. Click OK to continue. The following dialog appears (see Figure 5-34):
Figure 5-34 - Reset Device Dialog
4. Click OKto complete the save process
5. To download an XML file containing all of the settings defined on the Setup page to the local
machine, click Download Setup to PC. The following dialog appears (see Figure 5-35):
Figure 5-35 - Download Setup File
6. Click OK to confirm.
5.5. Defining OPT Settings
To define Payment Terminal settings for the OrPAY1000, click the OPT button on the Forecourt homepage.
The following screen appears (see Figure 5-36):
OrPAY1000 Installation and Setup Manual 62
