Figure 5-4 - Forecourt Admin Homepage
The Admin settings page has the following navigation buttons on the left side of the screen:
Home:Basic device information
Setup:Main device settings
Status:Displays current hardware status
Software Upload:Uploads software/firmware updates, assets, fonts, etc.
Back to Main:Returns to the Forecourt homepage
5.3.1. Home
The Admin Home page displays current device information (see Table 5-1):
Field Description
MAC MAC address
IP IP address
Netmask Netmask address
Version Version number
BootLoader Boot Loader version
Date/Time Real Time Clock
S/N Serial number
Location Installation location
Table 5-1 - Device Information
5.3.2. Setup
The Setup page is comprised of four tabs: Minimal Setup, General Setup, Log Level, and Save. Click on the
Setup navigation button to view and define the parameters in each tab.
OrPAY1000 Installation and Setup Manual 38
