Figure 5-36 - OPT Homepage
The OPT settings page has the following navigation buttons on the left side of the screen:
Home:Basic device information
Setup:Main device settings
System: Defines the services and hardware features of the device
Back to Main:Returns to the Forecourt homepage
5.5.1. Home
The OPT Home page displays current device information (see Table 5-16):
Field Description
Version Firmware version
Device Address Device Address
Contactless Contactless firmware version
Keyboard Keyboard firmware version
Keyboard Boot Keyboard boot loader version
Assets Asset version
Fonts Font version
Table 5-16 - Device Information
5.5.2. Setup
The Setup page is comprised of three tabs: General Setup, Log Level, and Save. Click on the Setup navigation
button to view and define the parameters in each tab.
5.5.2.1. General Setup
The Setup page opens with the General Setup tab selected (see Figure 5-37).
63 OrPAY1000 Installation and Setup Manual
