6.3.2. Reinstallation
To reinstall the OrPAY1000, proceed as follows:
1. Place the OrPAY1000 carefully onto the surface, and align it with the screw-holes
2. Place the screws into the OrPAY1000 but don’t tighten them. Verify that the OrPAY1000 is properly
aligned, and then tighten the screws
3. Pass the wires through the rubber isolator in the back
4. Plug in the LAN cable / RS-485 and the low-voltage power cable, and reconnect the ground wire
5. Use new cable ties to secure the cables to the OrPAY1000. Verify that the cables are tied so that
they will not be snagged or pinched when the door is opened and closed
6. Switch on the mains power supply and check that the OrPAY1000 powers up correctly
7. Check that the OrPAY1000 comes online, and then close the door
OrPAY1000 Installation and Setup Manual 72
