Section 4 Installation
4.1. General
This section provides instructions for installing the OrPAY1000. While the guidelines deal primarily with the
requirements for mounting onto a fuel pump-head, the steps are applicable to any type of cabinet.
4.2. Installation Procedures
This section provides instructions for installing the OrPAY1000 on a new pump or cabinet in four different
ways:
On the door / front of the pump
On the wall near the pump
On top of the pump
For pump retrofit
The installation procedure includes the following steps:
1. Installation of the OrPAY1000 in the prescribed location
2. Cable connections
3. Post-installation checks
The following must be taken into consideration when installing more than one OrPAY1000 unit:
LF tag reading suffers from interferences when 2 OrPAY1000 units are placed close to each other,
depending on the configuration:
1. Back-to-back:
If the units are installed without the metallic back cover, then the minimum distance
required between the units is 50cm
If the units are installed with the metallic back cover, then the minimum distance
required between the units is 20cm
2. Side-by-side: The minimum distance required between the units is 20cm
HFtag (MiFare)reading
Version 01.00.57 and up solves the Mifare issue encountered with OrPAY1000
Strictly observe all the safety instructions detailed in Precautions and Safety Information.
4.2.1. Installation Template
The OrPAY1000 is fastened by means of four M4 x 16 screws to the mounting surface. The fastening screws
pass through holes in the bottom plate of the OrPAY1000. In addition, a 5 mm hole located at the center of
the unit is required to pass the connection cable.
OrPAY1000 Installation and Setup Manual 26
