ATEX (Explosive Atmospheres): The OrPAY1000 has openings that prevent it being gas-tight, and
consequently it must be located away from any hazardous zone. Refer to local laws and regulations for
hazardous zones to determine a suitable mounting arrangement for the OrPAY1000. The enclosure in which
the OrPAY1000 is mounted should also be designed to prevent a dangerous build-up ofexplosive gases.
Security
The enclosure must provide sufficient physical security to protect the public from the hazards within, as well
as reduce the possibility of tampering with the outdoor payment terminal.
Power & Data
a. The enclosure must provide mains power with the following requirements:
A permanently-wired connection or a socket
A protective earth connection
b. The enclosure must provide an Ethernet data connection with the following requirements:
Capable of at least 10Mbps (preferably 100Mbps)
The connection must be either a socket into which a standard Ethernet patch cable can be
connected, or a cable that is terminated in a standard RJ45 plug suitable for direct
connection into the outdoor payment terminal's LAN socket
Minimum cable standard should be CAT5e STP(Shielded)
c. The enclosure may provide an alternative data connection for terminals that have optional
communications modules installed. Please consult with Orpak for what options are available
Accessibility
The enclosure must be designed and mounted so that disabled persons are able to operate the outdoor
payment terminal.
Materials
The enclosure and all its components must be constructed of durable materials suitable for the intended
location.
Water Tightness
The OrPAY1000 is rated for IP65 on its display and keyboard. The parts sitting inside the pump / pedestal
enclosure are designed to reduce the likelihood of rain drops entering the electronics, but the enclosure
must provide good protection from water. The door should have a water seal against the enclosure, and
there should also be drainage and / or a system to reduce excessive condensation build-up and dripping.
3.3.1. Power Supply Requirements
The OrPAY1000 kit does not include a power supply, customers must provide their own power supply when
designing the installation. The power supply must be compliant with the following protocols:
Use an external ACto DCor DCto DC switching power supply transformer, make sure it is an
approved model according to local regulations and in compliance with IEC 60950-1 normal location
safety standards
Maximum low voltage / low current:200VA, even under fault conditions
When using an ACto DC transformer, use ONLY one of the following:
SELV &Limited Power Source (marked LPS)
NECClass III
OrPAY1000 Installation and Setup Manual 22
