Parameter Value
Certifications
CE
FCC ISED Canada
ATEX zone 2 II 3G Ex nA IIB T4 IP65 Gc
cULus Class I Division 2, Groups A, B, C & D Hazardous Locations
UL Notes:
T-code T3C:
THE UNIT IS TO BE MOUNTED ON A SUITABLE ENCLOSURE SUCH THAT
FIELD WIRING REMAINS INTERNAL AND THAT IT BE ACCESSIBLE ONLY
WITH THE USE OF A TOOL. SUITABLE FOR USE IN CLASS I, DIVISION 2,
GROUPS A, B, C, D HAZARDOUS LOCATIONS ONLY
Note: This is not an exhaustive list and requirements may differ from
country to country.
2.4.2. External Interfaces
The following details the various types of ports supported by OrPAY1000.
2.4.2.1. Serial Port
OrPAY1000 supports the following serial ports:
RS232-level, 5-wire (RxD, TxD, RTS, CTS, GND)
Unshielded RJ45 female connector
Wired as Data Terminal Equipment (see Table 2-10)
8 OrPAY1000 Installation and Setup Manual
