Pin Signal

1 TX1

2 RX1

3 GND

4 485_1-

5 485_1+

6 GPIO

7 TX2

8 RX2

9 GND

10 485_2-

11 485_2+

12 E

13 V-

14 V+

Table 2-10 - Serial Port Pinout

2.4.2.2. USB Port

The USB-A connector with standard pin-out is in the following table (see Table 2-11):

Pin Signal

1 +5V

2 D-

3 D+

4 GND

Table 2-11 - USB Port Pinout

2.4.2.3. LAN Port

OrPAY1000 supports the following LAN ports:

Ethernet

10/100 baseT

Shielded RJ45 female connector (see Table 2-12)

OrPAY1000 Installation and Setup Manual 9
