Figure 5-26 - MPI-CBoard

9 8 7 6 5 4 3 2 1

E GND BYPASS INUSE PULSE VOUT SSR

Channel 1/2

Table 5-10 - MPI-C Pinout

For more details, see Available Configurations: MPI-C

5.4.2.2.3. TokheimSetup Settings

The following details the channel settings required for a Tokheim pump interface.

55 OrPAY1000 Installation and Setup Manual
