GlobalPowerTechnologies 3-17
5120
Item Part # Description
3.6 5120 Burner with Flame Arrestor Parts
B1 4000-00983 BurnerBackAssembly
B2 4000-01004 InsulationBlockSupport
B3 4000-00701 Spacer,Insulation
B4 4000-00693 ScreenHolder
B5 4000-00873 BurnerScreen
B6 4000-00694 InsertRing
B7 4000-00998 InsulationBlock
B8 4000-00971 Venturi
B9 4000-00999 VenturiTubeHolder
B10 2506-00479 Screw,Set,Soc.HD,6-32x1/8,SS
B11 4000-00985 BurnerCoverAssembly
B12 4900-27148 FlameArrestorCanAssembly
B13 2900-00549 Ring,Retaining,SS,39-5122-18-H
B14 4000-01005 Spacer,Burner
Figure 225120BurnerwithFlameArrestor
