2.3 Data Plate
ThedataplateislocatedontheinsideoftheTEGcabinetdoorandindicatesthefollowing:
Fuel Type:AnXisstampedintheappropriateboxforNaturalgasorPropane.Eachfueltype
requiresadi󰀨erentorice,thereforetheTEGmustbeusedwiththefuelindicated.
Model Number:Themodelnumberisinterpretedasfollows:
Serial Number: UniquetoeachTEG.
Power, Fuel Pressure, Voltage:Theseweremeasuredduringthefactoryperformancetest
andareforreferenceonly.Theoperatingpower,fuelpressureandvoltagearedeterminedand
adjustedasperSection2.6.
2.4 Fuel Supply
Fuel Considerations
Clean Fuel:Thefuelusedtooperatethe5120TEGmustbeclean(seegasspecicationsin
Appendix,page7-3).Ifdirtyfuelisanticipatedthenacustomersupplied,in-linefuellteris
recommended.
Low Temperature:  When using propane (C
3
H
8
) at
temperaturesbelow-30ºC(-22ºF)specialconsideration
mustbegiventothelowvapourpressureofthefuel.
Pressure:Makesurethatfuelpressureisatleast69
kPa (10 psig) and will not exceed 172 kPa (25 psig).
Ifit isexpectedthatthefuelsupplypressure willvary
greatly,theuseofanadditionalprimaryregulatorisrec-
ommended.Thiswillholdtheinputpressurerelatively
constant.
ChecktheTEGdataplateforthefueltype.DONOT
useadi󰀨erenttypeoffuelthanindicated.
DONOTAPPLYSEALANTON
THEFIRSTTWOTHREADS
APPLYTHREADSEALANT
OVERTHISAREA
07193rev1
Figure 3ApplyingThreadSealant
Fuel Type: L= Propane
  N= NaturalGas
Limiter Converter Voltage:
12or24Volts
Fuel System:
SI =SparkIgnitionOnly
SI-SO =SparkIgnition&AutoShutO󰀨
5120 - ( ) - ( ) ( )
