APPENDIX E – DATA
SYNCHRONIZATION INPUT CONNECTORS
 TNC
 18dB
IRIG-B / AFNOR NFS 87500
1000 Hz * 2,2V p-p to 8 Vp-pp
Connecteurs 2 points
 DB9
Ethernet 10/100BaseT RJ45
GPS ANTENNA
Dimensions
3,05’’ D x 2,61’’ H
775mm x 662mm
 -40°C to 85°C
 RG59, 25m, 60m, 80m
 18 dB
STANDARD OUTPUT
 Connector
10 MHz sine wave BNC
10 MHz square wave BNC
SNMP, HTTP - Ethernet 10/100BaseT RJ45
Two static relay alarms
(Power Supply, Synchronization)
4 pins conn.
