Gorgy Timing LEDI NETWORK iTS - Page 122

122
MDE-LEDInetworkITS-server-4078V1.3

 Connector Accuracy
1 output - NTP - Ethernet 10/100BaseT RJ45
500µs to
1ms
4 outputs - IRIG-B / AFNOR NFS 87500 1000 Hz
(8,8V p-p)
8 pins conn.
20µs
(1000Hz)
4 outputs - ASCII RS422, RS485
(unidirectional)
1*DB9. 500µs
4 outputs - ASCII RS232
(unidirectional)
1*DB9 500µs
4 outputs –
IRIG B DCLS (TTL, differential TTL) or congurable
pulse (PPS, DCF…)
► static relay (350 V AC/DC, 130 mA)
► TTL (rise time :10ns)
► differential TTL (r.t. : 10ns) 4 sorties –
8 pins conn.
500µs
100ns
100ns
SMPTE 2 pins conn.
NETWORK PROTOCOLS
► Network Time Protocol (NTP)
► NTP v2 (RFC 1305), NTP v3 (RFC 1305), NTP v4
► SNTP (RFC 2030)
► UDP / TCP Time Protocol (RFC 868)
► SNMP v1 (RFC 1157)
► MIB II (RFC 1213)
► DHCP (RFC 2131)
► HTTP / HTML (RFC 2616)
► TELNET (RFC 854 to 861)
CONFIGURATION
HTTP conguration.
« GT Network Manager » software for Windows
®
NT/XP/2000.
TELNET.
NTP CLIENT
In option : NTP/SNTP synchronization software for Windows
®
NT/XP/2000. 10 users licence.
APPENDIX E – DATA
