Smart Control Operation
28 3A3393C Operation
Measure Mode
Measure Mode replaces a tape measure to measure
distances when laying out an area to be striped.
1. Use to select Measure Mode.
2. Press and release gun trigger control. Move striper
forwards or backwards. (Moving backwards is a
negative distance.)
3. Press and release gun trigger control to end mea-
sured length. Up to six lengths are viewable.
The most recent measured length is also saved as the
measured distance in the Stall Calculator display. See
Stall Calculator, page 30.
Press and hold gun trigger control at any time to apply a
dot. If trigger is held while striper is moving, a dot is
marked every 12-inches (30.5cm).
Ref. Description
1 Hold to reset values to zero.
MEASURE MODE
I/O
....
0.00
'
0.00
'
0.00
'
0.00
'
0.00
'
0.00
'
....
ti18564b
