Graco LineLazer V250SPS - Component Identification (LLV 250 DC Shown)

Component Identification (LLV 250DC Shown)
3A3393C Operation 7
Component Identification (LLV 250DC Shown)
1 Paint filter, both sides
2 Adjustable pad
3 Engine fuel cap
4 Wheel motor bypass valve
5 Straight line adjuster
6 Gun trigger lock
7 Displacement pump, both sides
8 Brake
9 Operator platform
10 Serial label under operator platform
11 Rear gun arm mount, both sides
12 Hydraulic fill cap/dipstick
13 Prime/drain valve, both sides
14 Handle bar height adjustment knob
15 Two paint hoppers (15 gallon/56 liter)
16 Hydraulic oil filter
17 Front gun mount, both sides
18 Steering handle
*LLV 250SPS has only 1 paint hopper and 1 pump.
