Technical Specifications
38 3A3393C Operation
Technical Specifications
Wetted Parts: PTFE, Nylon, polyurethane, V-Max,
UHMWPE, fluoroelastomer, acetal, leather, tungsten
carbide, stainless steel, chrome plating, nickel-plated
carbon steel, ceramic
LineLazer V 250DC (Models 17H471, 17H472)
U.S. Metric
Dimensions
Height (with handle bar down) Unpackaged - 50.5 in.
Packaged - 63.5 in.
Unpackaged - 128.3 cm
Packaged - 161.3 cm
Width Unpackaged - 33.0 in.
Packaged - 45.0 in.
Unpackaged - 83.8 cm
Packaged - 114.3 cm
Length (with platform down) Unpackaged - 73.5 in.
Packaged - 78.0 in.
Unpackaged - 186.7 cm
Packaged - 198.1 cm
Weight (dry - no paint) Unpackaged - 752 lbs
Packaged - 890 lbs
Unpackaged - 341 kg
Packaged - 404 kg
Noise (dBa)
Sound Power per ISO 3744: 103.1
Sound Pressure measured at 3.3 feet (1m): 86.5
Vibration (m/s
2
) (8 hours daily exposure)
Hand Arm (per ISO 5349) 1.6
Whole Body (per ISO 2631) 0.4
Power Rating (Horse Power)
Power Rating (Horse Power) per SAE J1349 11.9 HP @ 3600 rpm 8.8 kW @ 3600 rpm
Maximum Delivery 2.5 gpm 9.5 lpm
Maximum Tip Size
1 gun
2 gun
3 gun
.055
.039
.033
Inlet paint strainer 16 mesh 1190 micron
Outlet paint strainer 50 mesh 297 micron
Pump inlet size 1 in. NSPM (m)
Pump outlet size 3/8 NPT (f)
Hydraulic reservoir capacity 1.25 gallons 4.73 liters
Maximum hydraulic pressure 1825 psi 124 bar
Maximum working pressure 3300 psi 228 bar, 22.8 MPa
Maximum forward speed 10 mph 16 kph
Maximum reverse speed 6 mph 9.7 kph
Electrical Capacity 14 A @ 3600 rpm
Starting Battery 12V, 33Ah, Sealed lead acid
