Errors
74 3A2098S
WED_ 55 V/P Error Voltage to Pressure
Transducer error
Alarm Problem detected with
V/P
Verify outlet pressure
transducer is installed
and/or connected cor-
rectly
Replace if necessary
WJ1_ 56 Dispense Valve 1
Error
Dispense valve 1 error Alarm Problem detected with
dispense valve 1
Verify dispense valve 1
is installed and/or con-
nected correctly
Replace if necessary
WJ2_ 57 Dispense Valve 2
Error
Dispense valve 2 error Alarm Problem detected with
dispense valve 2
Verify dispense valve 2
is installed and/or con-
nected correctly
Replace if necessary
WJ3_ 58 Dispense Valve 3
Error
Dispense valve 3 error Alarm Problem detected with
dispense valve 3
Verify dispense valve 3
is installed and/or con-
nected correctly
Replace if necessary
WJ4_ 59 Dispense Valve 4
Error
Dispense valve 4 error Alarm Problem detected with
dispense valve 4
Verify dispense valve 4
is installed and/or con-
nected correctly
Replace if necessary
WSD_ 60 Incompatible
Valve Settings
Incompatible settings
for multiple valve oper-
ation; attempted to dis-
pense
Alarm Attempted to dis-
pense simultaneously
from multiple valves
on the same fluid plate
with different pressure
settings
Check settings shown
on Fluid Plate x,
screen 2 (Mode Set-
tings)
Verify automation pro-
gramming
WSD5 60 Incompatible
Valve Settings
Incompatible settings
for multiple valve oper-
ation; attempted to dis-
pense
Alarm Attempted to dis-
pense simultaneously
from multiple valves
on the same fluid plate
with different pressure
settings
In the Discrete Gate-
way screens, change
the settings of the
simultaneously dis-
pensing valves to the
same pressure
Verify automation pro-
gramming
F7D_ 61 Closed Valve
Flow
System reading flow
meter pulses with
valve(s) closed
Alarm Dispense hose leak Check hose; replace if
needed
Flow meter providing
false pulses
Replace flow meter
sensor or calibrate
meter
Dispense valve not
operating correctly
Repair dispense valve
V2D_ 62 Low Analog Command cable ana-
log command dropped
below minimum value
of 1 V while dispensing
Deviation Bad or loose com-
mand cable connec-
tion
Check command cable
and connection
Entered command
mode incorrectly
Enter correct com-
mand code
Automation program
error
Verify correct automa-
tion program
Event
Code
Gateway
Error No. Event Name
Event
Description Event Type Cause Solution
Fluid Plate Events and Errors
