Models
12 3A0420ZAF
*Volume Mix Ratios - 70:1 (Fourth and Fifth Digits of Part Number)
# Components
†
Bare pump packages ending in zero require additional components to make a complete system.
See XP Proportioning Pump Packages on page 10.
‡ Ex Rated.
XP Systems without Pump Lowers
Fourth
and
Fifth
Digits
Pump
Ratio
(A/B)
A Side
Pump
B Side
Pump
Combined
Fluid
Output
cc/cycle
Fluid Flow
at 40 cpm
gpm (lpm)
Over-
Pressure
Relief Valve
Maximum Air
Working Pressure
psi (MPa, bar)
Fluid to Air
Pressure
Ratio
Maximum Fluid
Working Pressure
psi (MPa, bar)
xxx10x
1:1 L090C0 L090C0
180 1.9 (7.2)
Silver
95 (0.65, 6.5)
72:1
7250 (50, 500)
xxx15x
1.5:1
L085C0 L058C0 144 1.5 (5.6) 80 (0.55, 5.5) 91:1
7250 (50, 500)
xxx20x
2:1
L115C0 L058C0 174 1.8 (6.8) 95 (0.65, 6.5) 76:1
7250 (50, 500)
xxx25x
2.5:1
L14AC0 L058C0 203 2.1 (7.9)
100 (0.7, 7.0)
65:1
6500 (45, 448)
xxx30x
3:1
L14AC0 L048C0 193 2.0 (7.5)
100 (0.7, 7.0)
68:1
6800 (47, 469)
xxx40x
4:1
L14AC0 L036C0 181 1.9 (7.2)
100 (0.7, 7.0)
73:1
7250 (50, 500)
xxxxx0† xxxxx1‡ xxxxx2‡ xxxxx3‡ xxxxx4‡ xxxxx5 xxxxx6‡ xxxxx7 xxxxx8 xxxxx9
Pump Assembly
(Air Motor and Pump Lowers)
XXX X X XXX X X
Cart
XX X XXXXXX
XTRxxx Spray Gun and
35 ft Supply Hose
XX X XXXXXX
7 Gallon Hopper
X XXXXXX
Solvent Pump
X XXXXXX
A | B Fluid Heaters
X XXXXXX
Hose Heater and Water
Circulation Pump with
Remote Mix Manifold
XX X
Junction Box
X XXX
PressureTrak XX X
System Voltage
240
240 240
240
240 480 480
Hazardous Location/Ex
Rated
XXX X X
X
Part System
Maximum Fluid
Working Pressure
psi (Bar, MPa)
Includes:
281000 XP35 3500 (24, 241)
Cart, XTRxxx Spray Gun and 35 ft
(10.7 m) supply Hose (not attached)
282000 XP50 5000 (34, 344)
571000 XP70 7250 (50, 500)
These packages without pump lowers are not operational and are not CE rated or Ex marked.
