Technical Specifications
3A0420ZAF 91
Technical Specifications
XP Proportioners
U.S.
Metric
Maximum Fluid Working Pressure
See Models section beginning on page 10.
Maximum Air/Hydraulic Oil Working Pressure
Combined Fluid Output (cc/cycle)
Pressure Ratio
Fluid Flow at 40 cpm
Hydraulic Fluid Consumption (XP-h models only) 0.2 gallons per cycle
0.76 liters per cycle
Maximum Pump Cycle Rate 40 cycles/min
Air inlet size 3/4 npsm(f)
Maximum air pressure supply to the system 175 psi
12 bar, 1 MPa
Fluid pump inlets without hoppers 1-1/4 in. npsm(m)
Fluid gauge manifold outlets 1/2 in. npt(f)
Fluid mix manifold inlets 1/2 in. npt(f) ball valves
Mix manifold material outlet 1/2 in. npt(f)
Maximum feed pressure from remote source 250 psi
17 bar, 1.7 MPa
Sound pressure 86 dBA at 100 psi (7 bar, 0.7 MPa)
Sound power 98 dBA at 100 psi (7 bar, 0.7 MPa)
Maximum Storage Time 5 years (To maintain original performance,
replace soft seals after 5 years of inactivity.)
Power Efficiency Factor (XP70) 75 cu. ft compressed air/1 gallon
sprayed material at 100 psi
2.12 cubic meters compressed air/1 liter
sprayed material at 7 bar (0.7 MPa)
Air consumption per 1 gallon (3.78 l) of flow
XP70 75 scfm at 100 psi/gpm
2.12 m
3
/min at 7 bar, 0.7 MPa
XP50 60 scfm at 100 psi/gpm 1/min at 7 bar, 0.7 MPa
XP35 50 scfm at 100 psi/gpm 1.42 cubic meters/min at 7 bar, 0.7 MPa
Electrical Specifications:
Configurable Voltage / Phase / Hz See Models on page 10. And Connect Power on page 24.
Full Load Amps See Models on page 10. And Connect Power on page 24.
Filtration:
Air inlet filtration 40-micron filter/separator included
XP pump outlets 30 mesh
XTR Spray Gun 60 mesh
Fluid Viscosity Range:
Gravity feed with 7 gallon (26 liter) hoppers 200 to 20,000 cps (pourable)
Pressure feed Any viscosity that will not require feed pressure more than
15% of outlet pressure
Ambient Temperature Range:
Operating 40° - 130° F
4° - 54° C
Storage 30° - 160° F
-1° - 71° C
Maximum Fluid Temperature 160° F
71° C
Wetted materials:
Housings and manifolds Carbon steel with electroless nickel plating
Miscellaneous parts Plated carbon steel, stainless steels, carbide, acetal, UHMWPE, nylon,
PTFE solvent resistant plastics
Pump packings Carbon filled PTFE, proprietary UHMWPE
Flush pump suction tube Aluminum
Hoses Nylon core

Graco XP70 Specifications

General

Fluid Output	2.0 gpm (7.6 lpm)
Fluid Delivery	2.0 gpm (7.6 lpm)
Maximum Fluid Working Pressure	7250 psi (500 bar)
Maximum Air Input Pressure	100 psi (7 bar)
Fluid Outlet Size	3/8 in npsm(m)
Wetted Parts	Stainless Steel, PTFE, UHMWPE
Maximum Pressure	7250 psi (500 bar, 50 MPa)
Hose Length	50 ft
