Graco XP70 User Manual

Models
3A0420ZAF 15
XP Proportioning Pump Packages
Packages include motor, pump lowers, and all
connection hardware.
Pump sizes are marked on the pump cylinder; sizes are
nominal. See technical data in your Xtreme
displacement pump manuals for actual displacement.
Building systems with bare proportioning pump
packages:
• Over Pressure Protection must be used, see
page 9. See chart on page 52 to identify the over
pressure relief valves to use with your system.
• All components must meet or exceed maximum
working pressures.
Type
Pump
Package
A Side
Pump
B Side
Pump
Volume
Mix
Ratio
Combined
Fluid
Output
cc/cycle
Pressure
Ratio
Fluid Flow
at 40 cpm
gpm (lpm)
Maximum Fluid
Working
Pressure
psi (MPa, bar)
Maximum Air/
Hydraulic Oil
Working Pressure
psi (MPa, bar)
Over
Pressure
Relief
Valve To
Use
XP-h with
Viscount II
Hydraulic Motor
284101 L22AC0 L22AC0
1.0:1
435 1.75:1 4.6 (17.4) 3150 (22, 217) 1800 (12, 124) Purple
284102 L14AC0 L14AC0 293 2.63:1 3.1 (11.7) 4700 (32, 324) 1800 (12, 124) Gold
284103 L090C0 L090C0 180 4.21:1 1.9 (7.2) 7150 (49, 493) 1700 (12, 117) Silver
284201 L29AC0 L14AC0
2.0:1
435 1.75:1 4.6 (17.4) 3150 (22, 217) 1800 (12, 124) Purple
284202 L18AC0 L090C0 274 2.81:1 2.9 (11.0) 5050 (35, 348) 1800 (12, 124) Gold
284203 L115C0 L058C0 170 4.39:1 1.8 (6.8) 7200 (50, 496) 1650 (11, 114) Silver
284251 L29AC0 L115C0
2.5:1
407 1.88:1 4.3 (16.3) 3400 (23, 234) 1800 (12, 124) Purple
284252 L18AC0 L072C0 255 3.02:1 2.7 (10.2) 5000 (34, 345) 1650 (11, 114) Gold
284253 L14AC0 L058C0 199 3.77:1 2.1 (7.9) 6800 (47, 469) 1800 (12, 124) Silver
284301 L29AC0 L097C0
3.0:1
388 1.97:1 4.1 (15.5) 3500 (24, 241) 1800 (12, 124) Purple
284302 L22AC0 L072C0 293 2.63:1 3.1 (11.7) 4700 (32, 324) 1800 (12, 124) Gold
284303 L14AC0 L048C0 189 3.95:1 2.0 (7.6) 7100 (49, 490) 1800 (12, 124) Silver
284401 L29AC0 L072C0
4.0:1
360 2.10:1 3.8 (14.4) 3800 (26, 262) 1800 (12, 124) Purple
284402 L22AC0 L054C0 274 2.80:1 2.9 (11.0) 5000 (34, 345) 1800 (12, 124) Gold
284403 L14AC0 L036C0 180 4.21:1 1.9 (7.2) 7150 (49, 493) 1700 (12, 117) Silver

Graco XP70 Specifications

General

Fluid Output	2.0 gpm (7.6 lpm)
Fluid Delivery	2.0 gpm (7.6 lpm)
Maximum Fluid Working Pressure	7250 psi (500 bar)
Maximum Air Input Pressure	100 psi (7 bar)
Fluid Outlet Size	3/8 in npsm(m)
Wetted Parts	Stainless Steel, PTFE, UHMWPE
Maximum Pressure	7250 psi (500 bar, 50 MPa)
Hose Length	50 ft
