Parts
64 3A0420ZAF
XP70 Systems
Ref. Part Description
Quantity
xxxxx1
xxxxx2
xxxxx3
xxxxx4
xxxxx5
xxxxx6
xxxxx7
xxxxx8
xxxxx9
1 26C338 CART, XP 111111111
2 262476 HUB, axle 111111111
3 118841 Washer, flat, 5/8 222222222
4 - - - - - PUMP assembly See page 78 for details
5 100133 Washer, lock,3/8 555555555
6 100101 SCREW, 3/8-16 x 1.0 in. 444444444
7 113362 WHEEL, semi-pneumatic 222222222
8 154628 WASHER 222222222
9 113436 RING, retaining 222222222
10 124410 BEARING, sleeve 111111111
11 124664 WASHER, 1.0 in. 222222222
12 262477 AXLE 111111111
13 191824 WASHER, spacer 444444444
14 113807 WHEEL, flat free 222222222
15 258982 HANDLE, cart 111111111
16 101242 RING, retaining 222222222
17 26C417 MODULE, air controls (see page 49 for details) 111111111
18 100131 Nut, hex, 3/8-16 111111111
19 25E211 LABEL, XP operation 111111111
20 248927 KIT, mixer element (25 pack) 333333333
21 111218 CAP, tube, square 444444444
22 158491 FITTING, nipple 446666666
23 15M987 FITTING, elbow, 60 224444444
24 H75003 HOSE, 7250 psi 222222222
25 H73825 HOSE,7250 psi, 3/8 in. x 10 ft 111111111
26 15B729 COUPLING 111111111
27 262478 HOUSING, mixer 333333333
29 150287 COUPLING, pipe, 1/4 X 3/8 111111111
30 H72510 HOSE, 7250 psi, 1/4 in. x 10 ft 111111111
31 XTR702 GUN, XTR 7 111111111
32 162024 COUPLING, 222222222
35 262806 MANIFOLD, recirc, XP70 (see pg 70 for details) 111111111
36 262807 MIX MANIFOLD 111111111
37 106212 SCREW, manifold mounting 222222222
38 116139 GRIP, handle 222222222
41 158683 FITTING 224444444
47 206995 FLUID, TSL, 1 quart 111111111
48 101566 NUT, lock 222222222
49 15U654 LABEL, identification, A/B 111111111
50 555357 SCREW, 1/4-20 x 0.5 in. 444444444
51 124450 CLAMP, spring
2 222222
52 124293 BOLT, u-bolt 111111111
53 124259 BRAKE, plunger clamp 111111111
54 124291 PIN, spring 222222222
55 24E872 BRACKET, hopper
2 222222
