Graco XP70 - XP Pump Package Component Lists

Parts
3A0420ZAF 81
XP Pump Package
Replacement safety labels, tags, and cards are available at no cost.
Ref. Part Description Qty.
901 262465 PLATE, motor 1
902 262466 ROD, tie, 4.0 in. long 3
904 262467 ROD, adapter 1
905 262468 ROD, tie, 14.25 in. long w/ shoulder 4
906 262469 ROD, tie, 14.25 in. long, 1.25 in. dia. 2
907 154636 WASHER, flat 3
908 101712 NUT, lock, 5/8 - 11 9
909 16D451 NUT, yoke 1
910 262470 BRACKET, ratio indicator 1
911 262471 YOKE, pump assembly 1
912 15H392 ROD, adapter, Xtreme 2
913 262472 SLEEVE, with bearing 2
916 123976 RING, snap, external 2
921 26C436 KIT, cover, air motor 1
921b 17X148 PLATE, finger guard 2
921c 16P338 SCREW, hex head, #10-32 x 0.25 in. 2
921d 111192 SCREW, cap 2
922 262474 KIT, cover, pump 2
922a 121803 SCREW, button head, #10-32 x .5 in. 3
922b 124172 WASHER, nylon, #10-32 9
922c 124665 NUT, captive, #10-32 1
922d 15T468 LABEL, warning 1
930 124078 CLAMP, spring 1
931 15H108 LABEL, safety warning 2
934 262475 PLATE, ratio indicator 2
935 16E882 STRAP, lowers 2
940 244524 WIRE, ground
Ref. Part Description Qty.
Ref. Description Part Qty.
- XP35 Sprayer
28110X
57410X
28120X
57420X
28125X
57425X
262804
28130X
57430X
28140X
57440X
-
4 PUMP Assembly 281100 281200 262803 281300 281400 1
903 MOTOR, air XL34D0 XL34D0 XL34D0 XL34D0 XL34D0 1
917 PUMP, lower, A L090C0 L115C0 L14AC0 L14AC0 L14AC0 1
918 PUMP, lower, B L090C1 L058C0 L058C0 L048C0 L036C0 1
919 COUPLING, A 244819 247167 244819 244819 244819 1
920 COUPLING, B 244819 247167 247167 247167 247167 1
929 LABEL, XP-- 17X377 17X377 17X377 17X377 17X377 1
64 VALVE, safety 114055 16M190 113498 114055 103347 1
Ref. Description Part Qty.
- XP50 Sprayer
28210X
57510X
28215X
57515X
28220X
57520X
28225X
57525X
28230X
57530X
28233X
28240X
57540X
-
4 PUMP Assembly 282100 282150 282200 282250 282300 282330 282400 1
903 MOTOR, air XL65D0 XL65D0 XL65D0 XL65D0 XL65D0 XL65D0 XL65D0 1
917 PUMP, lower, A L14AC0 L14AC0 L18AC0 L18AC0 L22AC0 L18AC0 L22AC0 1
918 PUMP, lower, B L14AC0 L097C0 L090C0 L072C0 L072C0 L054C0 L054C0 1
919 COUPLING, A 244819 244819 244819 244819 244819 244819 244819 1
920 COUPLING, B 244819 247167 247167 247167 247167 247167 247167 1
929 LABEL, XP-- 17X376 17X376 17X376 17X376 17X376 17X376 17X376 1
64 VALVE, safety 113498 103347 113498 114055 113498 103347 113498 1
Ref. Description Part Qty.
- XP70 Sprayer
57110X
57610X
57115X
57615X
57120X
57620X
57125X
57625X
57130X
57630X
57140X
57640X
-
4 PUMP Assembly 571100 571150 571200 571250 571300 571400 1
903 MOTOR, air XL65D0 XL65D0 XL65D0 XL65D0 XL65D0 XL65D0 1
917 PUMP, lower, A L090C0 L085C0 L115C0 L14AC0 L14AC0 L14AC0 1
918 PUMP, lower, B L090C0 L058C0 L058C0 L058C0 L048C0 L036C0 1
919 COUPLING, A 247167 247167 247167 244819 244819 244819 1
920 COUPLING, B 247167 247167 247167 247167 247167 247167 1
929 LABEL, XP--
17X375 17X375 17X375 17X375 17X375 17X375
1
64 VALVE, safety
113498 116643 113498 113498 113498 113498 1
