P a g e | 97
GDS3705 User Manual
Version 1.0.1.16
Figure 81: System Health Alert Page
Table 30: System Health Alert
Enable System Health Alert
When this option is checked, then the GDS will send alert emails
regarding the events selected under Event Name section using the
already configured [Email Settings].
There are two options:
Real-Time: the GDS will be sending successively alert
emails every second.
Periodic: a Time Interval of 1~10080 minutes between each
email can be configured.
This would be the Email Subject title. Maximum characters number
is 256.
SIP Registration Status: When checked, Email will contain
Offline/Online indication for all 4 accounts.
System Running Status: When checked, Email will contain the
system uptime.
System Temperature: When checked, Email will contain
Temperature value of the system in °C and °F, as well as whether the
temperature is normal on not.
Event Notification
This page allows users to configure the event notification details that will be used by GDS3705 to
communicate to an HTTP server and Log Events. When the feature Enable and Configured, all the event
logs will be uploaded to server: RFID open door, PIN open door, SIP Call, Alarm, etc...
For instance, the GDS3705, after an RFID Card swiping, will send to the configured HTTP server the
following HTTP POST containing “Use card open door” event:
POST / HTTP/1.1
Host: 192.168.6.107
Authorization: Basic Og==
Connection: keep-alive
Content-Length: 90
Date: 2017-11-09; Time: 14:07:27; Event describe: Use card open door. Card ID: 378690700.
