Grandstream Networks GWN7610 User Manual

P a g e | 38
GWN7610 User Manual
Version 1.0.5.15
Table 7: Wi-Fi
Field
Description
Enable Wi-Fi
Check to enable Wi-Fi for the network group.
SSID
Set or modify the SSID name.
SSID Band
Select the Wi-Fi band the GWN will use, three options are available:
• Dual-Band
• 2.4GHz
• 5Ghz
SSID Hidden
Select to hide SSID. SSID will not be visible when scanning for Wi-Fi, to
connect a device to hidden SSID, users need to specify SSID name and
authentication password manually.
Wireless Client Limit
Configure the limit for wireless client. If there’s an SSID per-radio on a
network group, each SSID will have the same limit. So, setting a limit of 50
will limit each SSID to 50 users independently.
If set to 0 the limit is disabled.
Enable Captive Portal
Click on the checkbox to enable the captive portal feature.
Captive Portal Policy
Select the captive portal policy already created on the “CAPTIVE
PORTAL” web page to be used in the created SSID.
Security Mode
Set the security mode for encryption, 5 options are available:
• WEP 64-bit: Using a static WEP key. The characters can only be
0-9 or A-F with a length of 10, or printable ASCII characters with a
length of 5.
• WEP 128-bit: Using a static WEP key. The characters can only be
0-9 or A-F with a length of 26, or printable ASCII characters with a
length of 13.
• WPA/WPA2: Using “PSK” or “802.1x” as WPA Key Mode, with
“AES” or “AES/TKIP” Encryption Type.
• WPA2: Using “PSK” or “802.1x” as WPA Key Mode, with “AES” or
“AES/TKIP” Encryption Type. Recommended configuration for
authentication.
• Open: No password is required. Users will be connected without
authentication. Not recommended for security reasons.
WEP Key
Enter the password key for WEP protection mode.
WPA Key Mode
Select key mode (Pre-Shared Key or 802.1X Authentication).
