GXV3380 User Guide
Version 1.0.1.5
Figure 26: GXV3380 Top status Bar – Wi-Fi
Notifications in Status Bar
The following table describes the icons used on the status bar for notification purpose.
Table 7: GXV3380 Status Bar Notification Icons
Network connected via Ethernet cable.
Trying to connect to the network via Ethernet cable.
Network disconnected via Ethernet cable.
Handset is off hook.
Speaker is being used. (x)
RJ9 headset is connected.
RJ9 headset is being used for calls.
3.5mm earphone is connected.
3.5mm earphone is being used for calls.
Wi-Fi is enabled and still not connected.
