P a g e | 42

GXV3380 User Guide

Version 1.0.1.5

The phone is powered up using PoE.

Call forward is set up.

PPPoE is connected.

PPPoE is not connected.

Warning message.

System Settings in Status Bar

Slide down the top status bar and select System Settings. Users will see the following settings.

Figure 27: System Settings in Status Bar

Turn on/off LCD display.

Turn on/off DND. When DND is

on, all the calls to the registered

accounts will be blocked.

Turn on/off Bluetooth.

Turn on/off Wi-Fi.

Turn on/off the voice of

the phone

Go to phone Settings

Show more options
