Grandstream Networks UCM630 A Series - Figure 2:UCM6300 A Front View; Figure 3: UCM6302 A Back View; Figure 4:UCM6302 A Front View; Figure 5: UCM6304 A Front View

P a g e | 49
UCM630xA Series User Manual
Version 1.0.9.10
Figure 2:UCM6300A Front View
UCM6302A front and back view
Figure 3: UCM6302A Back View
Figure 4:UCM6302A Front View
UCM6304A front and back view
Figure 5: UCM6304A Front View
WAN port
LAN port
Reset
Heartbeat port
2x FXS ports
2x FXO ports
Ground
2x USB ports
SD card slot
Navigation keys
WAN LED
LAN LED
4x FXS LEDs
4x FXO LEDs
SD card slot
2x USB ports
Power LED
Heartbeat LED
OK button
USB ports
SD card slot
