P a g e | 70
UCM630xA Series User Manual
Version 1.0.9.10
IP Prefixlen
Enter the Prefix length for static settings. Default is 64
DNS Server 1
Enter the DNS server 1 address for static settings.
DNS Server 2
Enter the DNS server 2 address for static settings.
 Method: Route
When the UCM630xA has, method set to Route in network settings, WAN port interface is used for uplink
connection and LAN port interface is used as a router. Please see a sample diagram below.
Figure 17: UCM6302A Network Interface Method: Route
 Method: Switch
WAN port interface is used for uplink connection; LAN port interface is used as room for PC connection.
