FC9000-UM-251-9370 10-6
10 PARTS LIST
10.5 Y Drive Part
No. Part No. Description Q’ty Remarks Rank
1 U682126201 Motor, DMN37HE-003 1 Y Motor A
2 U621802113 Pulley, Motor, S2M024-ASSY 1 Motor Pulley C
3 U378012421 Belt, STS-60S2M248_124Z-R 1 Y Drive Belt A
4 U692180113 Cable, CA512211C 1 Y Motor Encoder Cable C
5 U692180092 Cable, CA512209B 1 Y Motor Extension Cable C
6 U792900740
Temperature Sensor Board, PN5122-07
2 For X and Y motor A
7 U692180182 Cable, CA512218B 1
Cable for Temperature Sensor Board
A
8 U621803271 Pulley, Y Drive Pulley Assy 1 A
9 U621800773 Dog, Cam Sensor 1 C
10 U621800793 Spring, Cam Shaft 1 C
11 Bush, D4L4 1 D
12 Bush, D4L3 1 D
13 Bush, D6L11 1 D
14 U621800741 Cam Shaft Holder C
15 U621803204 Bracket, Y Drive 1 D
16 U621803211 Adjustment Plate, Y Drive Shaft Tilting 1 D
17 U621803400 Belt, Y, 300S2M1183LW-C 1 FC9000-75 A
U621813000 Belt, Y, 300S2M1488LW-C 1 FC9000-100 A
U621823000 Belt, Y, 300S2M1793LW-C 1 FC9000-140 A
U621833700 Belt, Y, 300S2M2047LW-C 1 FC9000-160 A
18 U621800823 Guide, Y Flexible Cable 75 1 FC9000-75 D
U621810823 Guide, Y Flexible Cable 100 1 FC9000-100 D
U621820823 Guide, Y Flexible Cable 140 1 FC9000-140 D
U621830823 Guide, Y Flexible Cable 160 1 FC9000-160 D
19 U621803510 Plate, Y Belt Stopper Plate 2 C
20 U395430301 Spacer Shaft, BRB-330SE 1 Cross Cutter D
21 Bush, D6L11 2 D
22 U310068620 Roller B, 686ZZMC3PS2S 2 C
23 U621803323 Pulley, Y Tension Pulley 1 C
24 U621803312 Shaft, Y Tension Pulley Shaft 1 C
25 U621803303 Bracket, Y Tension Bracket 1 D
To Next Page
