GRAPHTEC FC9000-140 - Stand, Basket

FC9000-UM-251-9370 10-11
10 PARTS LIST
10.8 Stand, Basket
No. Part No. Description Q’ty Remarks Rank
1
U621801521 Side Stay, FC9-75/100
2
FC9000-75/100 C
U621821521 Side Stay, FC9-140/160 FC9000-140/160 C
2 U621801462 Foot Assembly, FC9 2 C
U792900775 Caster, NANSIN, DNB50B M8 4 NANSHIN, DNB50B M8 C
U621801510 Cap, Foot 8 C
3
U621801412 Center Bar, Stand FC9-75
1
FC9000-75 C
U621811412 Center Bar, Stand FC9-100 FC9000-100 C
U621821412 Center Bar, Stand FC9-140 FC9000-140 C
U621831412 Center Bar, Stand FC9-160 FC9000-160 C
4 U792900820 Right Stocker Bracket Assy 1 Refer to section 10.9 -
5 U792900825 Left Stocker Bracket Assy 1 Refer to section 10.9 -
6 U792600725 Position Clamper Assembly 2 C
7
U621801900 Stocker Shaft Assembly FC9-75
2
FC9000-75 C
U621811900 Stocker Shaft Assembly FC9-100 FC9000-100 C
U621821900 Stocker Shaft Assembly FC9-140 FC9000-140 C
U621831900 Stocker Shaft Assembly FC9-160 FC9000-160 C
8
U621801910 Stocker Shaft FC9-75
2
FC9000-75 D
U621811910 Stocker Shaft FC9-100 FC9000-100 D
U621821910 Stocker Shaft FC9-140 FC9000-140 D
U621831910 Stocker Shaft FC9-160 FC9000-160 D
9 U621269231 End Cap, Stocker Shaft 4 C
10 U621801211 Bracket, Basket Pipe 2 C
11
U621801750 Pipe, Basket FC9-75
2
FC9000-75 C
U621811750 Pipe, Basket FC9-100 FC9000-100 C
U621821750 Pipe, Basket FC9-140 FC9000-140 C
U621831750 Pipe, Basket FC9-160 FC9000-160 C
12
U621801850 Middle Pipe, Basket FC9-75
1
FC9000-75 C
U621811850 Middle Pipe, Basket FC9-100 FC9000-100 C
U621821850 Middle Pipe, Basket FC9-140 FC9000-140 C
U621831850 Middle Pipe, Basket FC9-160 FC9000-160 C
13 - Basket Base Bracket 4 Refer to section 10.10 -
14
U621801610 Cloth, Basket FC9-75
1
FC9000-75 C
U621811610 Cloth, Basket FC9-100 FC9000-100 C
U621821610 Cloth, Basket FC9-140 FC9000-140 C
U621831610 Cloth, Basket FC9-160 FC9000-160 C
15 U792900815 Roll Media Flange 2 772180930 C
Flange Cap Screw M5L16 16 D
Flange Cap Screw M5L10 8 D
