5 RECOMMENDED PARTS LIST

No. Part No. Description -75 -100 -140 -160 Remarks

U792900700 Main Board, FC90, PN5122-01 1 1 1 1

U792900710 Main Board, FC90RS-232C, PN5122-01 1 1 1 1

For optional RS-232C Model

2 U792900735 Cam Sensor Board, PN5122-06 1 1 1 1

3 U692180314 Flexible Cable, FFC512205D 1 1 1 1 Cam sensor

4 U792900725 Y Relay Board, PN5122-03 1 1 1 1

U692180273 Y Flexible Cable, FFC512201C 1 1 – –

U692180293 Y Flexible Cable, FFC512203C – – 1 1

6 U792900745 Pen Block Assembly, FC90 1 1 1 1

7 U682180300 Registration Mark Sensor, KR4012-GTLF 1 1 1 1

8 U792900720 Control Panel Board, FC90, PN5122-02 1 1 1 1

9 U692180302 Flexible Cable, Cont FFC, FFC512204 1 1 1 1

10 U682157130 LCD, BTG240128SFBWBGG 1 1 1 1

11 U682132431 Motor, UGJMEE-A7JGR34 1 1 1 1 X motor

12 U682126201 Motor, DMN37HE-003 1 1 1 1 Y motor

13 U792900740 Temperature Sensor Board, PN5122-07 2 2 2 2

For X and Y motor

14 U792900730 Pinch Roller Sensor Board, PN5122-04 1 1 1 1

15 U692180322 Flexible Cable, FFC512206B 1 1 1 1

Pinch Roller Sensor

16 U561080035 Media Sensor, PS117EL1 2 2 2 2 Paper Sensor

17 U682180270 Fan, 9A0924G404 1 2 2 2

18 U682260310 Power Supply Board, LFP150F-48-J1YD40.5 1 1 1 1

19 U378012421 Belt, STS-60S2M248_124Z-R 2 2 2 2 Motor belt

U621803400 Belt, Y, 300S2M1183LW-C 1 – – –

U621813000 Belt, Y, 300S2M1488LW-C – 1 – –

U621823000 Belt, Y, 300S2M1793LW-C – – 1 –

U621833700 Belt, Y, 300S2M2047LW-C – – – 1

21 U621352000 Push Roller 2 3 4 4

22 U792900870 Cutting mat, 30 m roll, W5T0.5 1 1 1 1 30 m roll
