EN - 15
USB PORT
See Figure 9.
NOTICE: DO NOT attempt to charge
accessories rated more than 4 amps as it
could damage the USB port or mower.
IMPORTANT: Ensure hearing protection and
audio devices do not interfere with ability to
hear the audible alarm.
Provides 5V of power to USB powered
accessories.
BATTERY CHARGER
See Figure 10.
Provides power to the battery pack when
plugged into the charge port.
VEHICLE CONTROL MODULE
See Figure 11.
Controls electrical components of the
machine.
HEIGHT-OF-CUT ADJUSTMENT
SYSTEM
Sets the height of cut.
HIGH / LOW SPEED SWITCH
See Figure 12.
Controls maximum drive speed:
• High speed position: 17.7 kph (11mph)
drive speed.
• Low speed position: 12.9 kph (8mph) drive
speed.
WARNING: AVOID INJURY.
Keep setting at low speed
until you learn how to operate
the unit.
Figure 11
Located behind seat near right fender
Figure 12
High
Speed
Low
Speed
