Gravely Pro-Turn EV 60 - Start the System; Operate Unit

EN - 25
Lower Center Bar
See Figure 25.
1. Remove hairpins from lock pins and
remove lock pins from hinge plate.
2. Lower center bar and secure with lock
pins and hairpins.
IMPORTANT: Return center bar to the raised
position when clear of obstacles.
START THE SYSTEM
1. Push PTO knob down to off position.
2. Move steering levers to neutral position.
3. Engage parking brake.
4. Insert key switch and turn to the on
position.
OPERATE UNIT
1. Ensure Live-to-Drive feature is activated.
See Home Screen on page 20.
2. Release parking brake.
3. Pull PTO knob up to on position.
NOTICE: Never engage the PTO if the
mower is plugged with grass or other
material. This may cause damage to the
motors.
4. Move steering levers to begin mowing.
WARNING: AVOID INJURY.
Lower the center bar only
when needed to drive under
an object. There is no rollover
protection with the center bar
in the lowered position. DO
NOT wear seatbelt when
ROPS is in lowered position.
Figure 24
Figure 25
WARNING: AVOID INJURY.
Move the steering levers
slowly and keep the mower at
slow speed until you learn how
to operate the unit.
Direction
of Travel
Lever Position
Forward Push both levers
forward from
neutral position.
Reverse Pull both levers
backward from
neutral position.
Right Turn Push left lever
farther forward
than the right
lever.
Left Turn Push right lever
farther forward
than the left lever.
Stop Return both
levers to neutral
position.
