EN - 26
NOTICE: Aggressive turning can scuff or
damage lawns. Always keep both wheels
rotating when making sharp turns. DO NOT
make turns with inside wheel completely
stopped. For minimum turning radius, slowly
reverse inside wheel while moving outside
wheel slowly forward.
For Best Mowing Results
• Cut grass when it is dry.
• Keep mower blades sharp.
• Keep mower deck properly leveled.
• Do not set height of cut too low. For very
tall grass, mow twice.
• Do not travel too fast.
• When mulching, only remove 1/3 of grass
length per cutting. Do not cut more than
2.5 cm (1") at any one time.
• Discharge clippings into areas already cut.
• Vary cutting pattern with each mowing.
• Do not allow grass or debris to collect
inside of mower deck. Clean after each
use.
STOP THE UNIT
1. Move steering levers to neutral position.
2. Engage parking brake.
3. Push PTO knob down to off position.
4. Turn key switch to off position and
remove key.
MOVE UNIT MANUALLY
Bypass electric brakes to move unit with
system off.
1. Remove key and wait for moving parts to
stop and for hot parts to cool.
2. Rotate footplate rearward until it locks
into place. See Figure 26.
3. Pull bypass handle and secure notch to
footplate ledge. See Figure 27.
4. Push unit to desired location.
5. To return footplate to operating position,
lift up on footplate and lower to close (or)
remove handle from footplate to close.
TRANSPORT UNIT
1. Push deck lift pedal completely forward to
engage transport lock. Release pedal.
2. Move unit to transport vehicle.
3. Engage parking brake and remove key.
4. Secure mower frame to transport vehicle.
NOTICE: NEVER secure unit to vehicle from
rods or linkages that could be damaged.
RELEASE TRANSPORT LOCK
1. Push deck lift pedal forward and lift
transport lock release lever.
2. Slowly return mower lift pedal to resting
position.
WARNING: AVOID INJURY.
Wait for all moving parts to
stop before leaving operator’s
position.
