EN - 16
BATTERY BUSBAR
See Figure 13.
NOTICE: AVOID DAMAGE! Batteries must
be carefully inserted vertically into busbar
with battery connection pins facing the center
of the machine. DO NOT drag batteries
across busbar fins to position.
Connects batteries to electrical system.
TRANSPORT LOCK RELEASE
LEVER
See Figure 14.
Releases deck from transport lock position.
EMI FILTER
See Figure 15.
Reduces electromagnetic noise that may
cause interference with electrical devices.
IMPORTANT: EMI filters must be used with
all chargers.
POWER CORDS
See Figure 16.
110V Power Cord
Provides 110V of power to main electrical
supply.
220V Power Cord
Provides 220V of power to main electrical
supply.
DECK LIFT PEDAL
Raises mower deck to change height-of-cut
setting.
