G1026 Heavy-Duty Shaper
Design Type ..................................................................................................... Floor Model
Overall Dimensions:
Table ........................................................................................................
21
3
⁄4" x 28
1
⁄4"
Table with Extension Wing ........................................................................
30
1
⁄2" x 28
1
⁄4"
Height (Includes Fence) ........................................................................................
39
1
⁄2"
Height From Table To Floor .....................................................................................
34"
Length ...................................................................................................................
30
1
⁄2"
Width .....................................................................................................................
28
1
⁄4"
Weight (Shipping) ............................................................................................. 353 lbs.
Weight (in place) .............................................................................................. 345 lbs.
Box Size ..................................................................................... 32" L x 25" W x 43" H
Footprint ........................................................................................................ 21" x 20"
Capacities:
Spindle Sizes ................................................................................................
1
⁄2",
3
⁄4", 1"
Spindle Lengths ..................................................................
1
⁄2" - 2
3
⁄4";
3
⁄4" - 3
1
⁄2"; 1"- 3"
Spindle Capacity Under Nut ................................................
1
⁄2" - 2",
3
⁄4" - 2
1
⁄2", 1" - 2
1
⁄4"
Spindle Travel ............................................................................................................
3"
Spindle Openings ........................................................................
1
3
⁄8", 2
3
⁄4", 4" and 5
1
⁄2"
Table Counter-bore .................................................................. 7" Diameter x
5
⁄8" Deep
Max. Cutter Diameter ..............................................................................................
5
1
⁄2"
Spindle Speeds ........................................................................ 7,000 & 10,000 R.P.M.
Spindle Bearings ................................................. Shielded & Lubricated Ball Bearings
Construction:
Table ....................................................................................Surface Ground Cast Iron
Fence Assembly ...................................................................Surface Ground Cast Iron
Body Assembly .............................................................................................. Cast Iron
Base ...................................................................................................Pre-formed Steel
Wing .....................................................................................Surface Ground Cast Iron
Motor:
Type ............................................................................TEFC Capacitor-Start Induction
Horsepower ......................................................................................................... 3 H.P.
Phase ⁄ Voltage .............................................................................Single Phase ⁄ 220V
Amps .........................................................................................................................
18
Cycle ⁄ R.P.M. ............................................................................60 Hertz ⁄ 3450 R.P.M.
Bearings ............................................................. Shielded & Lubricated Ball Bearings
Switch ........................................................... Magnetic w/ Thermal Overload Protector
Features:
.......................................................................... Independently Adjustable Split Fence
.................................................................... Magnetic w/ Thermal Overload Protector
..................................................................................................................Starting Pins
...................................................................................................................Hold Downs
...........................................................................................................................
Guard
.................................................................................................... Vertical Spindle Lock
...................................................................................................Standard Miter Gauge
