REF PART # DESCRIPTION REF PART # DESCRIPTION
101 P1026101 HANDLE 133A P1026133A THRUST BEARING 51103
102 P1026102 HANDWHEEL 135 PK06M KEY 5 X 5 X 10
103 PSS05 SET SCREW 3/8-16 X 3/8 136 P1026136 ELEVATION LEAD SCREW
104 PSS08 SET SCREW 5/16-18 X 1/2 137 P1026137 CARTRIDGE SLIDE
105 P1026105 SLEEVE 139 PRP24M ROLL PIN 5 X 16
107 PB07 HEX BOLT 5/16-18 X 3/4 140 PB58 HEX BOLT 3/8-16 X 2
108 P1026108 SHAFT MOUNT 140-1 PN08 HEX NUT 3/8-16
111 P1026111 WORM SHAFT 141 PLW04 LOCK WASHER 3/8
112 P1026112 GIB 142 PW07 FLAT WASHER 5/16
113 PN02 HEX NUT 5/16-18 143 PLW01 LOCK WASHER 5/16
114 PSS20 SET SCREW 5/16-18 X 1-1/2 145 PSS02 SET SCREW 5/16-18 X 3/8
115 P1026115 ELEVATION HOUSING 146 P1026146 V-BELT M7 X 690
116 PB72 HEX BOLT 1/2-13 X 2 147 P1026147 MOTOR PULLEY
117 PW01 FLAT WASHER 1/2 148 PB11 HEX BOLT 5/16-18 X 1-1/2
118 PLW07 LOCK WASHER 1/2 149 PB55 HEX BOLT 1/2-13 X 1-1/2
120 P1026120 POINTER 151 P1026151 MOTOR MOUNT PLATE
123 P1026123 POINTER MOUNT 152 P1026152 3H.P. MOTOR
126 PB19 HEX BOLT 1/4-20 X 1/2 153 PK15M KEY 5 X 5 X 35
128 P1026128 LOCK KNOB 154 PB09 HEX BOLT 5/16-18 X 1/2
130 PLN07 LOCK NUT 5/8-11 156 PW06 FLAT WASHER 1/4
133 P1026133 GEAR 156-1 P1026156-1 LOAD WASHER
