G1026 Heavy-Duty Shaper
-49-







Miter Gauge Parts Breakdown and List
REF PART # DESCRIPTION REF PART # DESCRIPTION
601A P1023401 KNOB 610 P1023410 STOP
602 P1023402 FLAT WASHER 5/16 611 P1023411 POINTER
603 P1023403 MITER GAUGE BODY 612 P1023212 SCALE
604A P1023404 ADJUSTABLE MITER BAR 613 PSS31 SET SCREW 10-24 X 5/8
607 PN07 HEX NUT 10-24 614 PRP50M ROLL PIN 1.5 X 13
608A PSS32 SET SCREW 10-24 X 3/4 615 P1023SL415 MITER HINGE PIN
609A PSS29 SET SCREW 10-24 X 1/4
