Grizzly G1026 Instruction Manual

-46-
G1026 Heavy-Duty Shaper
SPACERS
Spindle Parts List
spacers
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 PFH08 FLAT HD SCR 10-24 X 1/2 215 P1026215 3/4" SPINDLE
202 PR12M SNAP RING 35MM 216 P1026216 1" SPINDLE
203 P1026203 FLANGE 217 P1026217 DRAW BAR
204 P1026204 SPINDLE CARTRIDGE 218 P1026218 DRAW NUT
205 PK20M KEY 5 X 5 X 15 219 P1035201C 1/2" SPINDLE NUT
206 P6205 BEARING 220 P1026220D 3/4" SPINDLE NUT
207 PR11M SNAP RING 25MM 221 P1026221 1" SPINDLE NUT
209 P1026209 HOUSING 222 P1026222 PIN
210 PR14M SNAP RING 70MM 223 P1026223 1/2" SPINDLE WASHER
211 P1026211 PULLEY 224A P1026224A 3/4" SPINDLE WASHER
212 P1035218 TOOTHED WASHER 225A P1026225A 1" SPINDLE WASHER
213 P1025219 SPANNER NUT 226 P1026219 SPINDLE WRENCH SET
214 P1026214 1/2" SPINDLE
Bore Diameter Height Replacement Part #
1/2'' 1''
1/4'' G2454
1/2'' 1''
3/8'' G2455
1/2'' 1''
1/2'' G2456
1/2'' 1''
3/4'' G2457
3/4'' 1-1/4''
1/4'' G2460
3/4'' 1-1/4''
3/8'' G2461
3/4'' 1-1/4''
1/2'' G2462
3/4'' 1-1/4''
3/4'' G2463
1'' 1-1/2''
1/4'' G2466
1'' 1-1/2''
3/8'' G2467
1'' 1-1/2''
1/2'' G2468
1'' 1-1/2''
3/4'' G2469
1'' 1-1/2''
1'' G2470
1-1/4'' 1-3/4''
1/4'' G2472
1-1/4'' 1-3/4''
3/8'' G2473
1-1/4'' 1-3/4''
1/2'' G2474
1-1/4'' 1-3/4''
3/4'' G2475
1-1/4'' 1-3/4''
1'' G2476
