Grizzly MTS 43 AC E2 - General Description; Summary

118
GB
General Description
Summary
1 Engine housing
2 Fuel tank
3 Starter handle with starter
cable
4 Choke lever
5 Air lter cover
6 Ignition cable
7 Fuel pump and fuel hoses
8 Accelerator cable
9 Large cable clamps
10 Top shaft tube
11 Multifunction handle
12 Tube xing screw
13 Bottom shaft tube
14 Thread cutter
15 Protective cover / reel cap-
sule
16 Reel capsule
17 Thread reel
18 Metal cutting blade
19 Cutting head holder
20 Protective cover /
metal cutting blade
21 Small cable clamps
22 Switching element
23 Lifting ring for carrying strap
pic. 1
