Carefully remove both of the seals from the single row set of bearings and one seal from the
double row set of bearings.
1. Press the double row set of bearings into the front of the bearing block with the
remaining seal exposed.
2. Insert the outer race spacer into the rear of the bearing block and tighten the set screw.
CAUTION: The set screw must properly seat into the groove on the outer race
spacer or the spacer will be damaged.
3. Insert the inner race spacer into the bearing block.
4. Press the single row bearings into the rear of the bearing block.
5. Replace the front bearing housing cap.
6. Insert the pulley and shaft assembly into the bearing block and replace the bearing
locknut.
7. Tighten the set screw in the bearing locknut.
8. Install the rear bearing housing cap.
9. Place the bearing block assembly into position on the slicer and replace the Delrin slide
pads.
10. Replace the top slide block.
11. Replace the side mount block.
12. Install the spring, spring cage, spacer, and tension handle of the tensioning bolt.
13. Tighten all bolts.
14. Adjust the blade tracking.
